Compression Load Cell

We are a leading Manufacturer of s-type load cell, weighbridge load cell, single point load cell, compression load cell, stainless steel load cells and button load cell from Vadodara, India.

Product Details: -

Brand Sensortronics

Model 65114

Capacity 25-50 Ton

Material Stainless Steel

Ingress Protection IP67

Application Silo & Tank Scale

Features Hermetically Sealed

Load Cell Certifications OIML, NTEP

Output Sensitivity(FS) 2.0 +/-0.1 mV/V

Combined Error <= +/- 0.02

Creep Error (30 minutes) <= +/- 0.017

Accuracy Class OIML R60 C3

Temperature Effect on Zero <= +/- 0.0010

Temperature Effect on Output <= +/- 0.0007

Zero balance +/- 1% FS

Maximum Safe Overload 150% FS

Ultimate Safe Overload 300% FS

Recommended Excitation Voltage 5 to 15V DC

Maximum Excitation Voltage 25V DC

Input Resistance 1000 Ohm

Output Resistance 990 +/- 1010 Ohm

Insulation resistance at 50V DC >= 5000 M Ohm

Compensated Temperature Range -10 to +40 Deg C

Operating Temperature Range -35 to +65 Deg C

Load Cell Intervals (nLC)/Divisions 3000

We provide premium quality Compression Load Cell with the top class standards and performance

Features:

Simple Installation

ATEX and High Temperature versions available

Stainless Steel Load Sensor

Self-Centering column design with anti-rotation pin

Environmental protection IP68/IP69K

Tank Weighing
